Product WIM45-UNTL-0.3-BIM-UNT-LUAP6X4-H1141
Linear Position Sensor
For Analog Monitoring of Pneumatic Cylinders
Order number: 1536623- Plastic, PA12‐GF30
- For direct mounting on pneumatic T-groove cylinders
- Magnetic field status displayed via two LEDs
- Measured value storage
- Hardly affected by external magnetic fields
- 4‐wire, 15…30 VDC
- NO contact, PNP output
- Analog output
- 0…10 V
- Cable with male end M12 x 1
General data
| EAN | 4047101200515 |
| eCl@ss-Code (V5.1.4): | 27270104 -/- Magnetic inductive proximity switch |
| Customs tariff number | 90318020000 |
| Country of origin | DE |
| Weight | 23 g |
Technical Data
| Measuring principle | Magnetic |
| Measuring range | 45 mm [1.77 in] |
| Operating voltage | 15…30 VDC |
| Output function | NO contact, PNP/Analog output |
| Voltage output | 0…10 V |
| Electrical connection | Cable with connector, M12 × 1 |
| Housing material | Plastic, PA12-GF30/PP |
| Ambient temperature | -25…+70 °C |
| Protection class | IP67 |
