Product LI50P1-Q17LM1-LIU5X2-0.3-RS5
Inductive Linear Position Sensor
Order number: 1590725- Rectangular, plastic
- Versatile mounting options
- Positioning element P1-Li-QR14/Q17L, mounting elements 2 × M1.1-Q17L as well as 2 × M1.2-Q17L included in delivery
- LED indicates measuring range
- Immune to electromagnetic interference
- Extremely short blind zones
- Resolution, 12-bit
- 4‐wire, 15…30 VDC
- Analog output
- Programmable measuring range
- 0…10 V and 4…20 mA
- Cable with male end M12 x 1
General data
EAN | 4047101245752 |
eCl@ss-Code (V5.1.4): | 27270702 -/- Inductive linear position sensor |
Customs tariff number | 90318080000 |
Country of origin | DE |
Weight | 96 g |
Technical Data
Design | Profile |
Measuring principle | Inductive |
Measuring range | 50 mm [1.97 in] |
Operating voltage | 15…30 VDC |
Output function | Analog output |
Voltage output | 0…10 V |
Current output | 4…20 mA |
Electrical connection | Cable with connector, M12 × 1 |
Cable length | 0.30 m |
Housing material | Plastic, PC-GF10 |
Ambient temperature | -25…+70 °C |
Protection class | IP67 |
