Product RO18M-Q45L450-2RP5X2-H1181
Safety light screen
Receiver
Order number: 7700305- Male, M12 x 1, 8-pin
- Blanking function
- Protection class IP65
- Adjustments via DIP switch
- Operating voltage 24 VDC +‐15%
- Resolution 30 mm
- Scan field 450 mm
- Personnel safety Cat 4, PL e acc. to EN ISO 13849‐1:2008
- Type 4 acc. to IEC 61496‐1,‐2
- SIL 3 to IEC 61508
General data
| eCl@ss-Code (V5.1.4): | 27270910 -/- Light grid |
| Customs tariff number | 85365019000 |
| Country of origin | US |
| Weight | 1 g |
Technical Data
| Function | Light screen |
| Design | Rectangular |
| Scan field | 450 mm |
| Range | 100…18000 mm |
| Optical resolution | 30 mm |
| Cascadable | No |
| Start/Restart interlock | adjustable |
| Operating voltage | 20…28 VDC |
| Output function | 2 x NC contact, 2 × PNP |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Metal, AL, Yellow |
| Ambient temperature | 0…+50 °C |
| Protection class | IP65 |
Connectivity accessories
|
WKC8T-2/TEL
Connection cable, M12 female connector, angled, 8-pin, cable length: 2 m, jacket material: PVC, black; cULus approval |
6625133 |
|
RKC8T-2/TEL
Connection cable, M12 female connector, straight, 8-pin, cable length: 2 m, jacket material: PVC, black; cULus approval |
6625130 |
Functional accessories
|
IM73-23-R/24VDC
Interface module, 2 inputs, 3 NO outputs, 24 VDC, provides max. 6 A, 20 ms response time |
7700346 |
|
|
IM73-221-R/24VDC
Interface module, 2 inputs, 2 NO outputs, 1 NC auxiliary output, 24 VDC, provides max. 6 A, 20 ms response time |
7700345 |
