Product EOR23M-BR85-6X
Photoelectric Sensor
Opposed Mode Sensor (Emitter)
Order number: 7700692- Integrated terminal chamber
- Cable glands, offset installation by 90° in two places
- Protection class IP67
- Operating voltage: 10…48 VDC
General data
| eCl@ss-Code (V5.1.4): | 27270901 -/- Opposed mode sensor |
| Customs tariff number | 85365019000 |
| Country of origin | CN |
| Weight | 1 g |
Technical Data
| Function | Opposed mode sensor (emitter) |
| Design | Rectangular |
| Range | 0…23000 mm |
| Light type | Red |
| Operating voltage | 10…48 VDC |
| Electrical connection | Terminal chamber |
| Housing material | Plastic, ABS, Yellow |
| Ambient temperature | -25…+55 °C |
| Protection class | IP67 |
