Product LOP4.6M-BR85-RVDZ5X2
Photoelectric Sensor
Retroreflective Sensor with Polarizing Filter
Order number: 7700704- Integrated terminal chamber
- Cable glands, offset installation by 90° in two places
- Protection class IP67
- AID alignment aid
- Operating voltage: 12…240 VDC, 24…240 VAC
- Relay output
- Light and dark operation
- Sensitivity adjusted via potentiometer
General data
| eCl@ss-Code (V5.1.4): | 27270902 -/- Retroreflective sensor |
| Customs tariff number | 85437090990 |
| Country of origin | CN |
| Weight | 1 g |
Technical Data
| Function | Retroreflective sensor with polarizing filter |
| Design | Rectangular |
| Range | 80…4600 mm |
| Light type | Red |
| Operating voltage | 24…240 VAC / 12…240 VDC |
| Output function | NO/NC, Relay output |
| Electrical connection | Terminal chamber |
| Housing material | Plastic, ABS, Yellow |
| Ambient temperature | -25…+55 °C |
| Protection class | IP67 |
