Product T-BAT23S
glass fiber
bifurcated fiber
Order number: 7700805- Operating mode: Diffuse / retroreflective
- Stainless steel sheath, flexible
- Operating temperature: -140…+249 °C
- End sleeve for sensor, angled (90°), threaded
- Optical fiber, bundle diameter: 3.2 mm
- Optical fiber, total length: ± 914 mm
General data
| eCl@ss-Code (V5.1.4): | 27061090 -/- Ready-made optical fiber (not classified) |
| Customs tariff number | 90011090900 |
| Country of origin | US |
| Weight | 1 g |
Technical Data
| Construction size | 914 mm |
| Housing material | Stainless steel |
| Ambient temperature | -140…+249 °C |
