Product RO1.8M-Q10F-AP6X2
Photoelectric Sensor
Opposed Mode Sensor (Receiver)
Miniature Sensor
Order number: 7700476- Cable, 2 m
- Protection class IP67
- Glass lens
- Operating voltage: 10…30 VDC
- PNP/NPN switching output, light operation
General data
| eCl@ss-Code (V5.1.4): | 27270901 -/- Opposed mode sensor |
| Customs tariff number | 85365019000 |
| Country of origin | CN |
| Weight | 1 g |
Technical Data
| Design | Rectangular |
| Range | 0…1800 mm |
| Light type | IR |
| Operating voltage | 10…30 VDC |
| Output function | NO contact, light operation, PNP |
| Electrical connection | Cable |
| Cable length | 2.0 m |
| Housing material | Plastic, ABS, Black |
| Ambient temperature | -40…+70 °C |
| Protection class | IP67 |
