Product ROPL2M-MI-UNP6X-H1141
Photoelectric Sensor
Retroreflective Sensor with Polarizing Filter
Order number: 7700529- Male, M12 x 1, 4-pin
- Protection class IP67
- Sensitivity adjusted via potentiometer
- Alignment indicator
- Operating voltage: 10…30 VDC
- Switching output, bipolar
- Light/dark operation
General data
| eCl@ss-Code (V5.1.4): | 27270902 -/- Retroreflective sensor |
| Customs tariff number | 85437090990 |
| Country of origin | US |
| Weight | 1 g |
Technical Data
| Function | Retroreflective sensor with polarizing filter |
| Design | Rectangular |
| Range | 0…3000 mm |
| Light type | Red |
| Operating voltage | 10…30 VDC |
| Output function | NO contact, PNP/NPN |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Plastic, PBT, Yellow |
| Ambient temperature | -20…+70 °C |
| Protection class | IP67 |
Mounting accessories
|
TMBM18FA
Mounting bracket; material VA 1.4401, for 18 mm thread |
7700395 |
|
TMB18SF
Mounting bracket, PBT black, for 10 mm thread |
7700396 |
|
TMB3018SC
Mounting bracket, PBT black, for 18 mm thread |
7700397 |
|
TMBMIS
Mounting bracket, stainless steel, for BT18/BQ18 and ..-MI-.. |
7700401 |
Functional accessories
|
T-BRT-3
Round reflector, reflection coefficient 1.0, material acrylic, ambient temperature -20 … +60 °C |
7700369 |
