Product BSO2L250-BQ18-VP6X2-H1141-0.15
Photoelectric Sensor
Diffuse Mode Laser Sensor with Adjustable Background Suppression
Order number: 7700252- Cable with male end, M12 x 1, 4-pin, PVC, 150 mm
- Protection class IP67
- LED, all-round visible
- Cut-off point adjusted via potentiometer
General data
| eCl@ss-Code (V5.1.4): | 27270904 -/- Diffuse mode sensor with background suppression |
| Customs tariff number | 85437090990 |
| Country of origin | US |
| Weight | 1 g |
Technical Data
| Function | Diffuse mode sensor with adjustable background suppression |
| Design | Rectangular |
| Range | 1…250 mm |
| Light type | Red |
| Laser class | 2 |
| Operating voltage | 10…30 VDC |
| Output function | NO/NC, PNP |
| Current output | 100 mA |
| Electrical connection | Cable with connector, M12 × 1 |
| Cable length | 0.150 m |
| Housing material | Plastic, ABS |
| Ambient temperature | -10…+50 °C |
| Protection class | IP67 |
